Guardian beam does not render when over a certain "Time" in level.dat

Is this fixed for someone? If is, mark as Fixed. It is fixed for me

1.15.1 is already marked as affected, and I can reproduce this in 1.15.1 too. So this still is a problem for some players.

This happens in one of my worlds but not the other. It's quite annoying. Vanilla or not, resource packs or not, it still doesn't show. (in 1.15.2)

Also happened to me. Went to explore a Woodland Mansion and during the journey, I found an Ocean Monument. Tried to reproduce this and it happened. However, in creative, this doesn't work. You will see the beam normally, however, it is dark (MC-168398) Also, it is annoying. If you are above water, you do not know if it is attacking you, because you don't even see the bubbles (reason: MC-161917, which is very annoying.)

Welp, now I'm getting this issue. Apparently it doesn't happen in new worlds but will always not render on old worlds.

Big issue still present in 20w16a

@unknown, there is no need to say you confirmed for 20w16a. Saying you can also confirm this is enough. 20w16a is already in "Affects Versions" list.

How did Arisa add 19w40a? Is it because it is a bot?

When this gets fixed, I think that it will still be invisible, but optimizing the game should help, similar to MC-179845

Still present in 1.16 Pre-release 8

Still happens in 1.16.3, was wondering why I kept taking damage clearing out an ocean monument. All the beams were invisible.

Happens even when a world was created at 1.16.3, once it happens, this effect becomes permanent.
Optimizing, reloading chunks or resource packs won't have any effect.

Tried to re-create the world it happened to me at, the effect was visible, no idea what triggers it.

I found the bug cause:
After creating backups upon backups, deleting files in those backups...
When I tried to use NBTExplorer to modify the "Time" metadata in 'level.dat',
I found out that when this value reaches ~2800000 or above , this issue occurs.
Pasting this value or anything higher on a brand new world will have an 100% chance to cause this issue.

The fix for this is pretty easy, so easy I hope to see it implemented soon. The Guardian entity renderer alters the texture animation and other properties using the world tick time. Converting the world tick time to a float and using fractional render ticks causes overflows eventually.

The solution is dead simple and initially done by AMereBagatelle in this PR for the Sodium mod: https://github.com/jellysquid3/sodium-fabric/pull/419

It uses the current bounded day clock tick instead of the world tick. That is all.

Thanks!

Can confirm for 21w08b

Thanks @unknown for information, you are right.

I also attached a save where this occurs.

I just encounter this bug on my 1.17.1 server and sure enough the time is past 2800000.

Is it 2800000 exactly? Or does it happen at a power of two value like 2097152?

The bug is still unresolved on 1.18.1. I encounter it on a self-owned private Minecraft Vanilla server. I have checked the "Time" in level.dat is 21396082, seems not only happen at power of two values.

As mentioned by @unknown, the reason this issue occurs is because of an integer overflow, caused by float to int conversions inside Mth.cos() and Mth.sin(). More specifically, it should overflow when the world time is above approximately 2745160 (might be slightly more or less than that), as that is the earliest number that would cause an overflow within GuardianRenderer#render(...):

...
float $$8 = (float)$$0.level.getGameTime() + $$2;
...
float $$18 = $$8 * 0.05f * -1.5f;
...
float $$31 = Mth.cos($$18 + 5.4977875f) * 0.282f;
...
GuardianRenderer.vertex($$46, $$48, $$49, $$31, $$41, $$32, $$20, $$21, $$22, 1.0f, $$50);
...

Relates to MC-1279 and MC-63720

This bug is back using 1.19.3
